Denon AVR-X2800
Enjoy incredible 8K video and immersive 3D audio from the AVR-X2800H. Fill medium-size rooms with more refined sound from a 7.2 or 5.2.2 set up with Dolby Atmos and DTS:X. And with HEOS® Built-in, wirelessly stream online music and share with HEOS-enabled speakers in other rooms.
- Powerful sound: Fill a medium-size room with powerful, more refined sound.
- Immersive 3D audio: Feel fully enveloped in your music or movie sound.
- Geared for 8K: Enjoy amazing video quality from the latest 8K technology available.
- Music streaming throughout your home: With HEOS® Built-in, easily access streaming music and share with HEOS-enabled speakers in other rooms.
| Specifications |
|
| Multichannel Surround |
|
| DTS HD Master, DTS:X, DTS:X Pro |
o, o, |
| DTS Neo:X, DTS Neural:X |
-, |
| DTS Virtual:X |
|
| IMAX Enhanced |
|
| Dolby TrueHD, Dolby Atmos, Dolby Atmos Height Virtualization, Dolby Atmos Music |
o, o, o, |
| Dolby ProLogic Ilz, Dolby Surround |
-, |
| Auro 3D |
|
| 360 Reality Audio/MPEG H |
|
| Multichannel Stereo |
|
| Max Number of Processing (Preamp) Channels |
7.1 |
| Sound enhancements |
|
| Mono Block Power Amp Construction |
|
| Discrete Power Amplifier |
|
| D.D.S.C. HD Digital |
|
| Pure Direct |
|
| Gold Plated RCA Terminals |
|
| Clock Jitter Reducer |
|
| Alpha Processing |
|
| Audyssey |
MultEQ XT |
| Audyssey Dynamic EQ, Dynamic Volume |
o, |
| Audyssey LFC |
|
| Dirac Live Upgradability |
|
| Compressed Audio Restorer |
|
| Network |
|
| Media Server |
|
| HEOS Wireless Multi-Room Technology |
|
| Alexa/Google Voice Assistant/Apple HomePod |
o, o, |
| Lossy Formats: MP3, WMA, AAC |
o, o, |
| Lossless Formats: FLAC, ALAC, WAV |
o, o, |
| Lossless Formats: FLAC HD, WAV, ALAC (all 192kHz/24 bit) |
o, o, |
| DSD Audio Streaming |
(2.8/5.6MHz) |
| AirPlay 2 |
|
| TuneIn |
|
| Spotify Connect |
|
| Roon Tested |
|
| HEOS App Control |
|
| Compatible with Remote APP for Smart Phones |
Denon 2016 AVR Remote |
| Ethernet Ports |
|
| Wi-Fi |
|
| Bluetooth |
|
| HDMI |
|
| HDMI Inputs: Back, Front |
6, |
| HDCP2.3 support |
|
| HDMI Outputs: Main, Zone |
2 / |
| HDMI 2.1: 8K/60Hz AB, 4K/120Hz AB |
o, |
| HDR, HLG, Dolby Vision, HDR10+, Dynamic HDR |
, o, o, o, |
| ALLM (Auto Low Latency Mode) Pass-Through for Gaming |
|
| Variable Refresh Rate, Quick Flame Transport, Quick Media Switching |
o, o, |
| 3D Signal Pass-through |
|
| 8K Signal Pass-Through, Scaling, GUI Overlay |
o, o, |
| DSD Audio Capability |
|
| Audio Return Channel (ARC), Enhanced ARC |
o, |
| Auto LipSync |
|
| Multi-Room / CI |
|
| Multi-Room Zones |
2 |
| Zone Audio Source: HDMI; Optical, Coax, Network, USB; Analog |
(2ch), (2ch), o, |
| Zone Audio Output: Speaker, Pre-Out |
o, |
| Zone HDMI Output from HDMI Source |
|
| IP Control, RS232 Control, Web Control, App Control |
o, /o, |
| Remote In / Out |
o, |
| DC Trigger Output |
|
| HDMI Diagnostics |
|
| Others |
|
| Auto Speaker Setup by Microphone |
Audyssey MultEQ XT |
| Front Display |
1-Line FLD |
| GUI Languages |
3 |
| Setup Assistant |
|
| Quick Select Plus, Quick Select |
o, |
| Variable Crossover |
|
| Optimized Bass Redirection |
|
| Bass Sync |
|
| ECO Mode |
|
| Auto Power Off |
|
| Sleep Timer |
|
| Inputs/Outputs |
|
| HDMI In / Out |
6, 2 |
| Multi-room Video Out: Video / HDMI |
-, |
| Analog In, Out |
4, |
| Phono (MM) In |
|
| Digital In: Optical / Coaxial |
2, 1 |
| Multi-room Out: Analog / Digital |
1, |
| Multichannel Preout |
(0.2) |
| Subwoofer Out |
2 |
| Speaker Terminal: Gold Plated Screw / Regular Screw |
-, |
| Number of Speaker Terminals |
7 |
| Speaker A / B |
Assignable |
| Bi-amp Drive |
Assignable |
| Multi-Room Speaker Terminal |
Assignable |
| Front Inputs: Audio / Composite / Digital (Opt) / HDMI / USB |
-, -, -, -, |
| USB Audio / Made for iPod / Made for iPhone |
o, -, |
| AM/FM Tuner |
|
| Specifications |
|
| Number of Poweramps |
7 |
| Power Output (8 ohm, 20 Hz - 20 kHz, 0.08% 2ch Drive) |
95W |
| Power Output (8 ohm, 20 Hz - 20 kHz, 0.05% 2ch Drive) |
|
| Power Output (6 ohm, 1 kHz, 0.7% 2ch Drive) |
125W |
| Power Output (6 ohm, 1 kHz, 10% 1ch Drive) |
185W |
| General |
|
| Metal Front Panel |
|
| System Remote Control |
RC-1253 |
| Pre-programmed / Learnable / LCD Display |
-, -, |
| Power Consumption in W |
500 |
| Power Consumption No-Sound (ECO On / Off) in W |
35W/75W |
| Standby Consumption in W |
0.1 |
| CEC Standby Consumption in W |
0.5 |
| Network Standby Consumption in W |
Less than 2.0 |
| Maximum Dimensions |
|
| Weight in LBS |
21.0 |
| Weight in lbs (Packaging) |
25.4 |
